Wheels and castors are mechanical devices, generally applied to equipment and carriages, which must comply with handling requirements involved in production processes. Usually handled manually, they are used at a speed of less than 4 km/h, with non-continuous duty.
The wheel and castor must be fitted to the equipment using appropriate, correctly tightened bolts and nuts.
When connecting the swivel castor stem, be particularly careful to check the surface flatness of the assembly, and avoid welding.
The structure and the carriage, as well as the point of fitting wheels and castors, must have a suitable dimensions for carrying the required load.
Swivel castors should be mounted so that their axles are perpendicular to the ground.
Fixed castors must be mounted so that the wheel axle (rear or front) are aligned.
For use in environments which are humid or saline, or with exposure to outdoor weather conditions or caustic chemicals, specific products should be requested.
The selection of the wheels and castors to be used at temperature of less than +10oC or greater than +30oC should be carefully examined.
Immediately replace wheels that show early wear or deformation under a load.
In order to correctly select the most suitable product, all the elements which can influence that choice should be examined beforehand, including: load, temperature, speed, working environment, etc.
With a load greater than the capacity indicated.
On non-suitable floor surfaces.
At temperatures which are to high or too low.
In the presence of caustic chemicals.
With exposure to violent impacts or stress.
At a speed of greater than 6km/h.
With any modification not previously approved by the manufacturer.
By combining product components not product by the same manufacture.
Pressed Steel zinc plated finish; swivel assemblies having a double ball race head assembly & Kingpinless design.
Available Options:
Furniture
Light Duty Grey Non Marking
Imperial Series
White Nylon
Polyurethane on Nylon (Plain & Roller Bearing)
Polyurethane on Nylon (Ball Bearing)
Rubber Tyred Plastic Centred
Rubber Tyred Steel Disk Centred
Rubber Tyred Grey Non Marking
Synthetic Blue Elastic Rubber
Synthetic Rubber on Aluminium Centre
Hi Temperature Phenolic
Cast Iron with Ball Bearing
Rubber Tyred Cast iron Ball Bearing
Polyurethane Cast Iron Centred Ball Bearing
Pressed Steel zinc plated finish; swivel assemblies having double ball bearing, hardened raceways head assembly. Leading brake pedals.
Available Options:
Nylon Ball Bearing
Polyurethane on Nylon Ball Bearing
Cast Iron Ball Bearing
Rubber Tyred Cast Iron Ball Bearing
Polyurethane on Cast Iron Ball Bearing
Pressed Stainless Steel; swivel assemblies have a double ball race head assembly, Kingpinless design. AISA 304 material.
Available Options:
Nylon
Polyurethane on Nylon (Plain & Roller Bearing)
Hi Temperature Phenolic
Rubber Tyred Grey Non Marking
Synthetic Blue Elastic Rubber
Double ball bearing raceway heat treated for long wear and added strength.
Bright zinc plated, 5/8" bolted king pin, Top plate and fork 1/4" cold forged steel, 1/2" diameter axle bolt with lock nut, Grease fittings in swivel raceway with grease nipple.
Available Options:
Nylon Ball Bearing
Polyurethane on Nylon Ball Bearing
Polyurethane on Cast Iron Ball Bearing
Cast Iron Ball Bearing
Rubber Tyred Cast Iron Ball Bearing
Black Polymer Painted, Single Piece forged ally steel top plate and head assembly, precision CNC machined raceways, induction hardened raceways ensures uniform depth of hardness. Totally sealed swivel head, 6mm thick fork material robotically welded inside and out ensures high strength. 12mm axle hole, directional lock slots fitted as standard.
Available Options:
Nylon Ball Bearing
Polyurethane on Nylon Ball Bearing
Polyurethane on Cast Iron Ball Bearing
Cast Iron Ball Bearing
Rubber Tyred Cast Iron Ball Bearing
Black Polymer Painted, Single Piece forged ally steel top plate and head assembly, precision CNC machined raceways, induction hardened raceways ensures uniform depth of hardness. Totally sealed swivel head, 6mm thick fork material robotically welded inside and out ensures high strength. 12mm axle hole, directional lock slots fitted as standard.
Available Options:
Nylon Ball Bearing
Polyurethane on Nylon Ball Bearing
Polyurethane on Cast Iron Ball Bearing
Cast Iron Ball Bearing
Rubber Tyred Cast Iron Ball Bearing
Black Polymer Painted, Single Piece forged ally steel top plate with an integrally forged Kingpin, forged fork base, combination of thrust ball bearing (DIN 711) and tapered roller bearing (DIN 720) in the swivel head. Totally sealed swivel head with grease nipple, 8mm thick legs cylindrically formed and robotically welded inside and outside, 16mm wheel axle diameter.
Available Options:
Nylon Ball Bearing
Polyurethane on Cast Iron Ball Bearing
Cast Iron Ball Bearing
Black Polymer Painted, Single Piece forged ally steel top plate with an integrally forged Kingpin, single forged fork base, combination of thrust ball bearing (DIN 711) and tapered roller bearing (DIN 720) in the swivel head. Swivel head play made adjustable by a slotted nut-cotter pin arrangement. Totally sealed swivel head with grease nipple, 10mm thick legs cylindrically formed and robotically welded inside and outside, 20mm wheel axle diameter.
Available Options:
Nylon Ball Bearing
Polyurethane on Cast Iron Ball Bearing
Cast Iron Ball Bearing
1500 KG: Black Polymer Painted, Single Piece forged ally steel top plate and head assembly, precision CNC machined raceways, induction hardened raceways ensures uniform depth of hardness. Totally sealed swivel head, 6mm thick fork material robotically welded inside and out ensures high strength. 12mm axles, directional lock slots fitted as standard.
Black Polymer Painted, Single Piece forged ally steel top plate with an integrally forged Kingpin, single forged fork base, combination of thrust ball bearing (DIN 711) and tapered roller bearing (DIN 720) in the swivel head. Swivel head play made adjustable by a slotted nut-cotter pin arrangement. Totally sealed swivel head with grease nipple, 10mm thick legs cylindrically formed and robotically welded inside and outside, 20mm wheel axle diameter.
The type of flooring and floor conditions influence rolling, performance and life of the wheels and castors. The reaction provoked by contact between the floor and the rolling tread, transmitted to the carriage and thus to the load depends on the following. Type of floor surface the presence of obstacles, Holes or tracks. Type of rolling tread and the diameter of the wheel. Which all need to be taken into account when making the correct wheel selection for the application?
Nylon
Polyurethane on Nylon
Rubber Tyred Plastic Centre
Grey Non Marking Plastic Centre
Rubber Tyred Steel Disk Centre
Synthetic Blue Elastic Rubber
Polyurethane on Cast Iron Centre
Cast Iron
Cast Iron Rubber Tyre
V-Grove Cast Iron
Hi Temperature Phenolic |
